RAMPF highlights expertise for gasketing on metal surfaces

IMTEX Forming 2016: Dispensing robot C-DR for cost effective automatic gasketing and dispensing of 2K PU-materials

Zimmern o. R., December 2015. RAMPF Production Systems, a leading provider of systems for processing one-, two-, and multi-component reaction resin systems, as well as automation solutions, is presenting its expert knowledge for gasketing on metal surfaces at IMTEX Forming 2016 – hall 2A, booth B107. The focus of the trade fair for the Indian metal forming industry at Bangalore International Exhibition Centre from January 21 – 26 will be the dispensing robot C-DR.

Used Plastic Machinery

RAMPF highlights expertise for gasketing on metal surfaces

FIPFG (Formed-In-Place-Foam-Gasket) systems stand for the cost-effective and easy automation of industrial manufacturing processes. The technology involves the application of a gasket directly to the workpiece using a two-component mixing and dispensing machine. The quick-drying gasket reacts within a couple of minutes and facilitates quick joining and assemblies. FIPFG can be used for gaskets of practically any shape or form, and on a number of different surfaces – including metal.

C-DR – cost effective entry into automatic gasketing and dispensing

“FIPFG seals and the associated automation are an unbeatable alternative to inlaid seals, as they provide an effective cost saving potential and guarantee the high-quality sealing of components in the metal forming industry,” emphasizes Hartmut Storz, Director of Sales & Marketing at RAMPF Production Systems. “Our compact and flexible dispensing robot C-DR offers a cost effective entry into automatic gasketing and dispensing of 2K PU materials.”

The C-DR robot is characterized by a compact and integrated design and can be easily operated via graphical color touch screen with user-guided IPC controller. The integrated RAMPF dispensing equipment with servo-driven gear pumps and servo-driven dynamic mixer as well as the nucleation controller ensure a reliable high-quality production. Flow rate, mixing ratio (from 100:100 – 100:10), and processing parameters can be freely adjusted.

DR-CNC – maximum flexibility for dynamic sealing, bonding, and casting

With more than 2,700 system solutions on the market, the product portfolio of RAMPF Production Systems ranges from the C-DR to the highly complex dispensing robot DR-CNC. With its separate material conditioning unit, the DR-CNC offers maximum flexibility for dynamic sealing, bonding, and casting. Variable X-Y-Z strokes also enable three-dimensional material application.

The Sinumerik 840D Solution Line control technology with OP08 operating panel means the DR-CNC combines the mixing and dispensing system with maintenance-free CNC linear axes. The result is flawless interplay between the dispensing process and axis motion sequences. Flexible automation solutions are also possible, from manual through to automatic part loading. There are a number of additional fit-out options, including rotary index tables, shuttle tables, conveyor lines, and customized automation.

Chemical and engineering competence from RAMPF

Used Plastic Machinery

RAMPF highlights expertise for gasketing on metal surfaces

The international RAMPF Group based in Germany offers customers material and machine from a single source. Whilst RAMPF Production Systems offers customers dispensing machines and automation for PU gasketing on metal parts, sister company RAMPF Polymer Solutions stands for first-class PU foam gaskets for the automobile, packaging, and electronics industries.

“For more than 35 years, we have been developing and manufacturing innovative sealing systems based on polyurethane and silicone,” says Albert Schmid, Key Technology Manager Foam Gaskets at RAMPF Polymer Solutions. “Our products and solutions stand for efficient sealing, highest quality, and easy handling. Key features include low water absorption, good adhesion, high long-term temperature resistance, and cost-efficient processing.”

Consulting, subcontracting, and support from Sanika Engineering & Consultancy

RAMPF is represented on the Indian market by its local service partner Sanika Engineering & Consultancy. The company uses dispensing machines from RAMPF Production Systems to manufacture sealing and bonding products for renowned customers amongst others in the automotive, electrics / electronics, energy, filter, and steel industry. “We are a leading end-to-end partner for materials, processing, and consulting on the Indian market and have been working closely together with RAMPF since 2009,” says Ulhas B. Peddawad, Managing Director of Sanika Engineering & Consultancy Pvt. Ltd.
